0-60021-4 PMI处理器自动化PLC

Description

0-60021-4    PMI处理器自动化PLC

产品描述
0-60021-4是信实电气的AutoMax。该设备的面板顶部写有PMI处理器。在它下面有一个绿色LED灯标记为OK，第二个绿色LED灯标记为COMM OK，然后一个红色LED灯标记为pm FLT，第二个红色LED灯标记为EXT FLT，第三个红色LED灯标记为RAIL FLT。灯的下面是标为P的标准型接线端子。仪表端口在左边，标记1到4在右边的块。下面是两个银色和黑色的小旋钮，彼此堆叠在一起，标记为P2和P3，统称为COMM Link。在这些旋钮下面是两个堆叠在一起的公端口，统称为P4轨道端口P5。上面的端口右边有一个0，下面的端口右边有一个1。AutoMax的后边缘有另一个雄性连接点。这比前面的大得多，并将板固定在机架上，与面板上的螺钉式锚一起。有三个大型微处理器和三十多个微芯片。0-60021-4还具有两个晶体振荡器和两个小型电感器。在0-60021-4板也有各种较大的电容器和电阻的一边与微芯片和更大的片。然而，背面有微型电阻器和微型陶瓷表面电容器。

0-60021-4

0-60021-4    PMI处理器自动化PLC

Product Description
The 0-60021-4 is an AutoMax from Reliance Electric. The faceplate of this device has PMI Processor written across the top. Below that there is a green LED light labeled OK, a second green LED light labeled COMM OK, then a red LED light labeled P.M. FLT, a second red LED light labeled EXT FLT, and a third red LED light labeled RAIL FLT. Below the lights is a standard type terminal block labeled P! Meter Ports on the left and labeled one through four on the right of the block. Below the block are two small silver and black knobs stacked on top of each other labeled P2 and P3 and collectively labeled COMM Link. Below these knobs are two male ports stacked on top of each other collectively labeled P4 Rail Ports P5. The upper port has a zero on the right side and the lower port has a one on the right side. The back edge of the AutoMax has another male connection point. This is much larger than the ones on the front and secures the board into the rack along with the screw style anchors on the faceplate. There are three large microprocessors and over thirty microchips. The 0-60021-4 also features two crystal oscillators and two small inductors. The 0-60021-4 board also has a variety of larger capacitor and resistors on the side with the microchips and larger pieces. However, the back side has micro resistors and micro ceramic surface capacitors.
