1771-OX 数字接点输出模块

Description

1771-OX 数字接点输出模块

Allen-Bradley 1771-OX是一个电源触点输出模块。本模块有4个N.O./N.C.输出点可用。该模块有四个状态指示灯，每个输出有一个指示灯。这些指示器表示输出继电器线圈的通电或断电状态。1771-OX也有一个保险丝，作为过载条件下的保护。当过载时，输出电路将被断开。

1771-OX模块的额定电压为交流有效值0 ~ 250v和直流有效值0 ~ 175v。它的最大额定电流为2a，额定功率为200va。该模块存在浪涌电流，这些浪涌电流为5.5A交流峰值，持续5秒，6A直流峰值，持续500秒，15A直流峰值，持续500毫秒。注意浪涌电流每10秒可重复一次。该模块还具有最大导通状态接触电阻0.25 Ω，最大背板电流550 mA，隔离电压2500V AC RMS。

该模块的信号延迟为10ms，无论开或关。功耗最小为2.6 W，最大为2.9 W。散热范围为8.9 BTU/hr ~ 9.9 BTU/hr。1771-OX的工作温度为0-60度

1771-OX

1771-OX 数字接点输出模块

The Allen-Bradley 1771-OX is a power contact output module. This module has 4 N.O./N.C. output points available. Four status indicators are present with this module, with 1 indicator per output. These indicators represent the output relay coils’ state of being energized or de-energized. The 1771-OX also has a fuse that serves as protection for overload conditions. In case of overload, the output circuit will be opened.

The voltage ratings of the 1771-OX module are 0-250V AC RMS and 0-175V DC. It also has a maximum current rating of 2 A and a power rating of 200 VA. Surge currents are present with this module and these are 5.5A AC peak for 5 seconds, 6A DC for 500 seconds, and 15A DC for 500 ms. Note that the surge current is repeatable every 10 seconds. This module also has a maximum on-state contact resistance of 0.25 Ω, a maximum backplane current of 550 mA, and an isolation voltage of 2500V AC RMS.

The signal delay of this module 10 ms for both on or off. Its power dissipation ranges from a minimum of 2.6 W to a maximum of 2.9 W. This module also has a thermal dissipation that ranges from a minimum of 8.9 BTU/hr to a maximum of 9.9 BTU/hr. The 1771-OX has an operating temperature of 0-60
