1783-CMS10DN 端口交换机

Description

1783-CMS10DN 端口交换机

Allen-Bradley 1783-BMS10CA交换机是一种管理型以太网交换机，共有10个端口。其中8个端口为铜端口，另外2个端口为combo端口。8个铜端口支持通过RJ-45接口进行快速以太网通信。combo端口通过RJ-45接口或光纤SFP插槽支持快速以太网通信。1783-BMS10CA交换机属于Stratix 5700系列以太网交换机。1783-BMS10CA开关上的报警继电器在30伏直流时额定电流为1安培，在48伏直流时额定电流为0.5安培。1783-BMS10CA交换机最大功耗为17w。开关的典型功耗为24伏直流12.5瓦。1783-BMS10CA开关的额定功耗为17瓦。

1783-BMS10CA交换机支持多种SFP模块，包括1783-SFP100FX、1783-SFP100LX、1783-SFP100EXC、1783-SFP100ZXC、1783-SFP100T、1783-SFP1GSX、1783-SFP1GLX、1783-SFP1GEXE、1783-SFP1GZX和1783-SFP1GTE模块。1783-BMS10CA交换机支持1784-SD1内存卡。交换机符合的行业标准包括IEEE 1613和IEC 61850-3标准。1783-BMS10CA开关的工作温度范围为-40至140华氏度。非工作温度范围从-40到185华氏度。交换机的外壳是打开的，尺寸为5.1 x 3.6 x 4.59英寸。为了确保开关周围的环境温度保持在建议的范围内，Allen-Bradley建议在开关周围保持至少2英寸的空间。直流电源线推荐使用20 ~ 18awg的铜线。

1783-CMS10DN

1783-CMS10DN 端口交换机

The Allen-Bradley 1783-BMS10CA switch is a managed Ethernet switch with a total of 10 ports. Eight ports are copper ports and the other two are combo ports. Eight copper ports support fast Ethernet communication via the RJ-45 port. combo port Supports fast Ethernet communication through an RJ-45 port or an optical fiber SFP slot. The 1783-BMS10CA switch is a Stratix 5700 series Ethernet switch. The alarm relay on the 1783-BMS10CA switch is rated for 1 amp at 30 V DC and 0.5 amp at 48 V DC. The maximum power consumption of the 1783-BMS10CA switch is 17w. The typical power consumption of the switch is 24 volts DC 12.5 watts. The 1783-BMS10CA switch is rated for 17 watts.

1783-BMS10CA switch supports multiple SFP modules, Including 1783-SFP100FX, 1783-SFP100LX, 1783-SFP100EXC, 1783-SFP100ZXC, 1783-SFP100T, 1783-SFP1GSX, 1783-SFP1GLX, 1783-SFP1GEXE, 1783-SF P1GZX and 1783-SFP1GTE modules. The 1783-BMS10CA switch supports 1784-SD1 memory cards. Industry standards for switch compliance include IEEE 1613 and IEC 61850-3 standards. The 1783-BMS10CA switch operates in a temperature range of -40 to 140 degrees Fahrenheit. Non-operating temperatures range from -40 to 185 degrees Fahrenheit. The switch’s housing is open and measures 5.1 x 3.6 x 4.59 inches. To ensure that the ambient temperature around the switch stays within the recommended range, Allen-Bradley recommends maintaining at least 2 inches of space around the switch. 20 to 18awg copper cables are recommended for DC power cables.
