1794-IB16XOB16P Flex 32点数字组合模块

Description

1794-IB16XOB16P Flex 32点数字组合模块

Allen-Bradley/Rockwell Automation 1794-IB16XOB16P模块是一款Flex I/O直流输入/输出模块。这种开放式模块具有16点24伏直流下沉输入，16点24伏直流源输出和24伏直流电源。它是一种可编程逻辑控制器模块，具有电子保护，具有IP 20 NEMA额定外壳，最大额定功率为125瓦。1794-IB16XOB16P模块只需要一个标准网卡就可以通过以太网局域网访问PLC主设备的数据。它与AC500系列PLC和外围设备相连，位于中央控制室。PLC主设备数据从I/O接收数据传输，进行相关处理和控制，由工业标准以太网TCP/IP通信模块(TB521ETH-)以10mbit /m的传输速率传输到工控计算机。

1794-IB16XOB16P模块的中央处理器(CPU)由控制器、算术模块和芯片寄存器组成。CPU通过数据总线、地址总线、控制总线和电源总线连接到存储器、I/O接口、编程器和电源。1794-IB16XOB16P模块可用于2线制系统和4线制系统，以及单端和差分模式。在开发平台开发完成后，用户需要设置I/O，然后根据每个模块的物理地址为CPU分配一个编号。

1794-IB16XOB16P

1794-IB16XOB16P Flex 32点数字组合模块

The Allen-Bradley/Rockwell Automation 1794-IB16XOB16P Module is a Flex I/O DC Input/Output Module.  This open-style module has a 16-point 24 Volts DC sinking input, a 16-Point 24 Volts DC sourcing output, and a 24 Volts DC power supply. It is a programmable logic controller module that is electronically protected and has an IP 20 NEMA rated enclosure and a maximum wattage rating of 125 Watts. The 1794-IB16XOB16P Module requires only a standard network card to access data from the PLC master device via the Ethernet LAN. It connects to an AC500 series PLC and peripheral equipment and it is located in a central control room.  The PLC master device data is transmitted from I/O receiving data, it performs correlation processing and control, and the industry-standard Ethernet TCP/IP communication module (TB521ETH-) transfers it to industrial control computers at a transfer rate of 10 Mbit/m.

The 1794-IB16XOB16P Module’s central processing unit (CPU) consists of a controller, an arithmetic module, and a chip register. The CPU is connected to the memory, the I/O interface, the programmer, and the power supply via a data bus, an address bus, a control bus, and a power bus. The 1794-IB16XOB16P module can be used in 2-wire systems and 4-wire systems and in single-ended and differential modes. After the development platform has been developed, the users need to set up the I/O and then they can assign a number to the CPU based on each module’s physical address.
