2094-BC04-M03-SC Allen-Bradley Kinetix 6000驱动系统模块

Description

2094-BC04-M03-SC Allen-Bradley Kinetix 6000驱动系统模块

2094- BC04-M03-S是一个Kinetix 6000驱动系统模块。该组件由Allen-Bradley制造,设计用作变频器的集成轴模块。该模块的额定输出功率在20%负载时为53瓦，40%负载时为72瓦，60%负载时为93瓦，80%负载时为116瓦， 100%负载时为142瓦。

该模块有一个转换器和逆变器部分。转换器部分的输出额定值为28kW,逆变器为30安培。该模块也称为AM电源模块。它配有用于电机电源(MP)和电机/电阻制动电源(BC)的接线插头连接器。该模块不提供目录号为2090-K6CK-D44M和2090-K6CK-D44S0的连接器套件输入和输出接口、安全和辅助反馈信号以及目录号为2090-K6CK-D15M的电机反馈。

使用该模块时，并不总是需要接地跳线设置。然而，不接地或高阻抗电源配置需要接地跳线设置。要设置接地跳线设置,请从电源轨上卸下集成访问模块(IAM ),打开电源模块并将跳线位置修改到适当的位置。默认情况下，模块设置为接地位置，其中P1 6和P17短路，而未接地配置的P18和P19端子短路。

安装2094-BC04-M03-S时，首先安装集成安讯士模块，然后安装IPIM、安讯士模块、分流模块和插槽填充模块。IAM必须安装在电源轨的最左侧。
其他模块位于IAM的右侧。

2094-BC04-M03-SC Allen-Bradley Kinetix 6000驱动系统模块

The 2094-BC04-M03-S is a Kinetix 6000 drive system module. The assembly was manufactured by Allen-Bradley and designed to be used as an integrated shaft module for a frequency converter. The rated output power of the module is in
At 20% load it is 53 watts, at 40% load it is 72 watts, at 60% load it is 93 watts, at 80% load it is 116 watts and at 100% load it is 142 watts.

The module has a converter and inverter section. The output rating of the converter section is 28kW and the inverter is 30 amps. This module is also called an AM power module. It comes with a power supply (MP) for motors and
Plug connector for motor/resistance brake power supply (BC). The module does not provide connector kit input and output interfaces, safety and security for catalog numbers 2090-K6CK-D44M and 2090-K6CK-D44S0
Auxiliary feedback signal and motor feedback with catalog number 2090-K6CK-D15M.

When using this module, it is not always necessary to ground jumper Settings. However, ungrounded or high-impedance power supply configurations require ground jumper Settings. To set the ground jumper Settings, remove the Integrated Access Module (IAM) from the power rail, turn on the power module and change the jumper position to the appropriate position. By default, the module is set to the ground position, where P6 and P17 are short-circuited, while the ungrounded terminals P18 and P19 are short-circuited.

When installing the 2094-BC04-M03-S, install the integrated Axis module first, followed by the IPIM, Axis module, shunt module, and slot fill module. The IAM must be installed on the leftmost side of the power rail.
Other modules are on the right of IAM.
