1X00102H01 Ovation配电板

Description

1X00102H01 Ovation配电板

1X00102H01配电板是在一块电木板上布置插座、开关、继电器等电气元件的简易配电屏。适用于沿海、远洋及江河船舶电站，直流220V以下,交流440V50Hz或450V60Hz电网。

配电板是在一块电木板, 木板或者其他材料上布置插座、开关、继电器等电气玩件的简易配电屏。
1X00102H01主配电板的制造符合GB/T11634-2000《船用交流低压配电板通用技术条件》、中国级社《钢质海船入级与建造规范》2006) 、《钢质内河船舶入级与建造规范》(2002版) 的有关要求。
配电板适用于沿海、远洋及江河船舶交直流电站，直流230V以下， 交流440V50Hz或450V60Hz电网,单机功率为12kW-900kW,用来控制与监视主发电机的工作，并将船电送来的电能或岸电送来的电能，通过主配电板向全船用电设备进行配电。

1X00102H01配电板分主配电板及应急配电板两种:
主配电板直接和主发电机相连，把主发电机发出的电能或岸电送来的电能分配至远外的二级1X00102H01分电装置或直接分配给用电负载;主电源失电后，应急配电板向- -些重要设备供电(如应急照明、操纵装置、导航和无线电设备等)。

ABBMD190(HONOR)’安亚’系列低压开关柜, 是经过TILVA和ASTA试验,并符合BS、IEC标准。 组件模数为190mm。开关柜结构可按用户要求扩展设备。

PDJ系列船用配电板适用于三相AC400V/50Hz或AC440V/60Hz、单机功率自20kW至1 600kW及DC30V以下船舶交直流系统，用来控制、监视和保护发电机。

1X00102H01

1X00102H01 Ovation配电板

The 1X00102H01 power distribution board is a simple power distribution panel that arranges electrical components such as sockets, switches, and relays on a power board. Suitable for coastal, ocean and river ship power stations, DC below 220V, AC 440V50Hz or 450V60Hz power grid.

A power distribution board is a simple power distribution panel in which sockets, switches, relays and other electrical devices are arranged on a board, wood or other materials.
The 1X00102H01 main switchboard is manufactured in accordance with the relevant requirements of GB/T11634-2000 “General Technical Conditions for Marine AC Low-voltage switchboard”, China Classification Society “Classification and Construction Code for Steel sea Ships” 2006), “Classification and Construction Code for Steel inland River Ships” (2002 edition).
The power distribution board is suitable for AC and DC power stations of coastal, ocean and river ships, DC below 230V, AC 440V50Hz or 450V60Hz power grid, single power is 12kW-900kW, used to control and monitor the work of the main generator, and send the electric energy sent by the ship or shore power. Power is distributed through the main switchboard to the electrical equipment of the whole ship.

There are two types of 1X00102H01 switchboards: main switchboard and emergency switchboard:
The main switchboard is directly connected to the main generator, and distributes the electrical energy sent by the main generator or the electrical energy sent by the shore power to the distant secondary 1X00102H01 distribution device or directly to the electric load; After the main power supply is lost, the emergency switchboard supplies power to some important equipment (such as emergency lighting, maneuvers, navigation and radio equipment, etc.).

ABBMD190(HONOR)’ Anya ‘series low-voltage switchgear is tested by TILVA and ASTA, and conforms to BS and IEC standards. The module is 190mm. Switchgear structure can be expanded according to user requirements.

PDJ series Marine switchboard is suitable for three-phase AC400V/50Hz or AC440V/60Hz, single-unit power from 20kW to 1 600kW and DC30V Marine AC/DC system, used to control, monitor and protect generators.
