增强型键相模块，如Bently 350025 125792-01，是一个半高、双通道模块，它的主要功能包括：

信号转换：当轴上的键相标记与键相传感器对齐时，模块接收来自接近探头或磁性拾音器的输入信号，并将这些模拟信号转换为数字键相信号。

提供键相信号：这些数字键相信号指示轴上的键相标记何时与键相传感器重合，为3500框架中的监视器模块提供关键的旋转位置信息。

支持多重配置：在正常配置中，3500机械保护系统最多可以接收四个键相信号。而在配对配置中，系统最多可以接收八个键相信号，从而支持更复杂的机械设备监测需求。

并行工作：当系统需要冗余（TMR）应用程序时，如三重模块需要系统键相输入，3500系统应使用两个Keyphasor模块。这两个模块可以并行工作，提供主要和辅助键相信号，从而增强了系统的可靠性和稳定性。

时间测量：键相位信号是来自旋转轴或齿轮的每转一次或每转多次的脉冲信号，提供的时间测量。这允许3500监测器模块和外部故障诊断设备用来测量诸如1X幅值和相位等向量参数。

总的来说，350025 125792-01增强型键相模块的主要功能是接收和处理来自传感器的信号，将其转换为数字键相信号，并提供给3500框架中的监视器模块，以实现旋转设备的精确监测和诊断。
