数字量输入模块是PLC（可编程逻辑控制器）系统中的一个重要组成部分，4351B主要用于接收来自工业现场的数字量信号，将这些信号转换为PLC内部可以处理的电平信号，并传送给CPU模块进行进一步的处理。

数字量输入模块可以连接工业现场的标准开关、二线制接近开关等数字量（或开关量）输出器件，它将这些器件的输出状态（如开/关）转换为二进制的数字信号（0或1），供PLC的CPU模块读取和处理。在处理过程中，CPU模块可以根据这些输入信号的状态来执行相应的控制逻辑，从而实现对工业过程的监控和控制。

数字量输入模块一般具有多个输入通道，可以同时接收多个数字量信号。此外，为了提高信号的抗干扰能力和传输距离，数字量输入模块通常还会采用光电隔离、继电器隔离等隔离措施。

数字量输入模块的工作原理主要涉及到信号采集、信号转换和信号传递三个过程。

首先，当用户使用如键盘、鼠标等外部设备进行操作时，这些设备会发出电信号。数字量输入模块的任务是对这些信号进行采集，也就是将这些电信号转换成计算机能够识别的数字信号。这个过程被称为信号采集。

其次，4351B采集到的电信号并不是计算机所能直接理解和处理的信号，因此需要进行信号转换。数字量输入模块会将采集到的信号进行转换，以便计算机能够正确地识别、处理并输出相关的操作效果。例如，开关量的信号通常为通断信号和无源信号，数字量输入模块会将其转换为计算机能够理解的二进制数字信号。

最后，经过信号转换的数字信号被传递到计算机的处理器中，通过计算机内部的程序来对信号进行处理、解析并输出操作结果。例如，计算机可以在屏幕上显示出用户在键盘上输入的字符，或者根据鼠标的移动轨迹进行相应的操作。这个过程被称为信号传递。

总的来说，4351B数字量输入模块的工作原理就是将外部设备的电信号采集并转换成计算机能够识别、处理的数字信号，然后将其传递给计算机处理器进行操作处理，从而实现用户与计算机之间的交互操作。
