8C-PAINA1 控制器

Description

8C-PAINA1 控制器

霍尼韦尔的8C-PAINA1控制器为分布式控制系统(DCS)提供强大而稳健的控制。8C-PAINA1是运行霍尼韦尔现场验证的确定性控制执行环境(CEE)核心软件的节点。CEE软件提供了优越的控制执行和调度环境。每个控制节点的控制策略都是通过一个通用的Control Builder(一个简单直观的工程工具)配置和加载的。

除了标准和健壮的预构建功能块和算法库外，8C-PAINA1控制器还支持自定义算法块(cab)。自定义算法块在目的和结构上与Control Builder分发的标准功能块相似。然而，cab具有用户定义的算法和数据结构，允许针对特定需求开发定制的策略。

8C-PAINA1控制器与系列8 I/O共享其硬件设计，提供创新设计，减少占地面积，减少安装和维护成本。C300控制模块安装在C300 IOTA (InputOutput Termination Assembly)上。8C-PAINA1 IOTA只包含无源设备，如FTE地址交换机。

本文档包含以下8C-PAINA1系列产品。
•TC / RTD
•模拟输入-单端
•模拟输入HART -单端
•模拟输入HART -差分
•模拟输出•模拟输出HART
•数字事件输入序列(SOE)
•数字输入，24 VDC
•数字输入脉冲积累•数字输出，24 VDC
•DO继电器扩展板

8C-PAINA1

8C-PAINA1 控制器

Honeywell’s 8C-PAINA1 Controller provides powerful and robust control for the distributed control system (DCS). The 8C-PAINA1 is a node in operating Honeywell’s field-proven deterministic Control Execution Environment (CEE)core software. The CEE software provides a superior control execution and scheduling environment. Controlstrategies for each controller node are configured and loaded through a common Control Builder, an easy andintuitive engineering tool.

In addition to a standard and robust library of pre-built function blocks and algorithms, the 8C-PAINA1 Controller alsosupports Custom Algorithm Blocks (CABs). Custom Algorithm Blocks are similar in purpose and structure to thestandard function blocks that are distributed with Control Builder. However, CABs have user-defined algorithmsand data structures, allowing custom tailored strategies to be developed to specific requirements.

The 8C-PAINA1 controller shares its hardware design with the Series 8 I/O, offering an innovative design that reducesfootprint and installation and maintenance costs. The C300 controller module is mounted on the C300 InputOutput Termination Assembly (IOTA). The 8C-PAINA1 IOTA contains only passive devices such as FTE addressswitches.

The following Series 8C-PAINA1 items areincluded in this document.
• TC/RTD
• Analog Input – Single Ended
• Analog Input with HART – Single Ended
• Analog Input with HART – Differential
• Analog Output• Analog Output with HART
• Digital Input Sequence of Events (SOE)
• Digital Input, 24 VDC
• Digital Input Pulse Accumulation• Digital Output, 24 VDC
• DO Relay Extension Board
