AC-800F AC 800F控制器

Description

XVME-6744 PC/AT处理器模块

AC-800F是一款功能强大的控制器，它支持过程自动化应用的所有主要现场总线，并且具有模块化结构，可以根据不同的应用需求连接不同的模块，如供电单元、以太网和现场总线模块。其主要特性包括：

1. 强大的处理能力：AC-800F配备了高性能的处理器，能够满足复杂的计算和控制需求。它提供了高速存取能力，可处理大量数据并执行实时控制任务。
2. 冗余设计：AC-800F支持多种冗余级别，包括设备冗余、电源冗余、以太网通信冗余以及Profibus DP的电缆冗余。这种设计确保了系统的可靠性和稳定性，即使主控制器出现故障，备用控制器也能迅速接管，保持系统的连续运行。
3. 灵活的通信能力：AC-800F使用Ethernet网络作为系统总线，支持多种类型的接点设备，实现过程控制站、操作员站和工程师站之间的对等通信。它支持同轴电缆、双绞线及光纤电缆等多种通信介质，提供了灵活的通信解决方案。
4. 丰富的I/O接口：AC-800F支持多种总线协议，如PROFIBUS-DPV1 FOUNDATION Fieldbus HSE MODBUS等，并且具有最大4个现场总线模件插槽，可以方便地连接各种现场设备。
5. 易于组态和配置：AC-800F的现场总线和设备连接能够完全通过Freelance工程师站软件进行组态和参数设置，无需其他外部软件工具，简化了配置过程。

XVME-6744 PC/AT处理器模块

The AC-800F is a powerful controller that supports all major fieldbuses for process automation applications and has a modular structure that allows different modules such as power supply units, Ethernet and fieldbus modules to be connected according to different application requirements. Its main features include:

Powerful processing power: The AC-800F is equipped with a high-performance processor to meet complex computing and control needs. It provides high-speed access to process large amounts of data and perform real-time control tasks.
Redundancy design: The AC-800F supports multiple redundancy levels, including device redundancy, power redundancy, Ethernet communication redundancy, and cable redundancy with Profibus DP. This design ensures the reliability and stability of the system, and even if the primary controller fails, the standby controller can quickly take over and maintain the continuous operation of the system.

Flexible communication capabilities: The AC-800F uses Ethernet networks as the system bus to support multiple types of contact devices, enabling peer-to-peer communication between process control stations, operator stations and engineer stations. It supports a variety of communication media such as coaxial cable, twisted pair cable and optical fiber cable, providing a flexible communication solution.

Rich I/O interface: The AC-800F supports a variety of bus protocols, such as PROFIBUS-DPV1 FOUNDATION Fieldbus HSE MODBUS, etc., and has up to 4 fieldbus module slots for easy connection to various field devices.

Easy configuration and configuration: The AC-800F’s fieldbus and device connectivity can be configured and parameterized entirely through Freelance engineer station software, eliminating the need for additional external software tools, simplifying the configuration process.
