AXLINK100 以太网和现场总线之间的通用网关

Description

AXLINK100 以太网和现场总线之间的通用网关

以太网正在成为自动化技术的主流通信媒介。aXlink100是自动化x软件(4.7及更高版本)的新设备，可实时连接Profibus和以太网。

功能aXlink100
>实时协议(Xlink)>高带宽
>支持冗余>防震冗余切换
>不同拓扑应用(线、环、树、树冗余拓扑)>环形拓扑，无需昂贵的光纤布线
>系统最大支持16个aXlink100 >冗余供电24V DC
>无需配置即可交换(地址切换)
>通过LED和协议进行诊断>顶帽导轨安装> Driver for automationX from version 4.7
>其他司机应要求

aXlink100将以太网与Profibus互连，其中使用了automationx开发的实时以太网协议Xlink。aXlink100集成了两个以太网接口，可作为8P8C (RJ45)或光纤选项，以及Profibus-DP主接口。这些接口允许多种系统和网络配置。

因此，该设备允许通过CAT5电缆配置电环或通过星形布局网络中的交换机配置网络和/或服务器冗余。因此，每个单元最多可以连接16个ProfibusMaster (aXlink100)和124个Profibus-DP slave到automationX。

AXLINK100

AXLINK100 以太网和现场总线之间的通用网关

Ethernet is becoming the prevailing communication medium in automation technology. The aXlink100, the newequipment available for the automationX software (version 4.7 and higher), connects Profibus with Ethernet inreal time.

Features aXlink100
> Real-Time protocol (Xlink)> High bandwith
> Redundancy capable> Shockproof redundancy change-over
> Different topologies application (line, ring, tree, tree topology redundant)> Ring topology without expensive optic fibre cabling
> Up to 16 aXlink100 per system> Redundant power supply 24V DC
> Exchangeable without configuration (address switch)
> Diagnostics via LED and protocol> Top hat rail mounting> Driver for automationX from version 4.7
> Other drivers on request

The aXlink100 interconnects Ethernet with Profibus, inwhich Xlink, a real time Ethernet protocol developed byAutomationX, is used. The aXlink100 incorporates twoEthernet interfaces, which are available as 8P8C (RJ45)or optic fibre option, as well as a Profibus-DP master interface. These interfaces allow a multiplicity of system andnetwork configurations.

Therefore this equipment allows the configuration of anelectrical ring via CAT5 cabling or a network and/or serverredundancy via switches in a star layout network with thisequipment. Thus it is possible to link up to 16 ProfibusMaster (aXlink100) with up to 124 Profibus-DP slaves perunit to automationX.
