CDP-01-MH DAC-00X传感器

Description

CDP-01-MH DAC-00X传感器

CDP-01设置通常会导致不正确或不需要的导向特性。故障和故障处理步骤在cdp-01参考手册“频繁设置错误”一章中有更详细的描述。下面的解释。故障诊断-故障处理故障:自动模式下，传感器移动方向错误。补救方法:选择“手动”模式，在边缘传感器模式(LED 10点亮)下改变驱动器3的极性(导向方向)。参考:CDP-01参考手册，章节:“改变导向方向”故障:在自动模式下，芯轴移动方向错误。补救措施:选择“手动”模式，并在特殊传感器模式(led 11和12亮)下改变驱动器2的极性(导向方向)。参考:CDP-01参考手册，章节:“改变引导方向”故障:在伺服中心模式下，传感器移动错误的方向。补救方法:选择“手动”模式，改变驱动器3的伺服中心极性。参考资料:CDP-01参考手册，章节:“伺服中心极性”。故障:在伺服中心模式下，芯轴移动到行程的任何一端，而不是到其行程的中心。补救方法:选择“手动”模式，改变驱动2的伺服中心极性。参考资料:CDP-01参考手册，章节:“伺服中心极性”。故障:在自动模式下，芯棒没有准确跟随传感器。补救措施:执行本文档中的“启动/传感器定位器与芯轴比率校准”程序

Fife CDP-01控制器

高级控制器提供自动设置功能,可实现快速、准确的操作

可切换115/220 VAC 50/60 Hz操作

于各种功能的并行接口:6个输入(远程控制)，2个输出(警报或指示灯)

自动调整连接的Fife电机

内置放大器,用于使用红外传感器进行透明网页检测

自动传感器控制-传感器信号佚(即断纸、卷筒末端)将自动切换到手动模式

CDP-01-MH

CDP-01-MH DAC-00X传感器

CDP-01 Settings often result in incorrect or unwanted orientation features. The fault and troubleshooting procedure are described in more detail in the chapter “Frequently Setting Errors” in the cdp-01 Reference manual. The following explanation. Fault Diagnosis – Troubleshooting Fault: The sensor moves in an incorrect direction in automatic mode. Remedy: Select “Manual” mode and change the polarity (guiding direction) of driver 3 in edge sensor mode (LED 10 lit). Reference :CDP-01 Reference Manual, section: “Change Direction” Fault: In automatic mode, the mandrel moves in the wrong direction. Remedy: Select “Manual” mode and change the polarity (guiding direction) of driver 2 in special sensor mode (led 11 and 12 on). Reference :CDP-01 Reference Manual, Section: “Changing the Guidance Direction” Fault: In servo-centered mode, the sensor moves in the wrong direction. Remedy: Select “Manual” mode and change the servo center polarity of drive 3. Reference :CDP-01 Reference Manual, Section: “Servo Center Polarity”. Failure: In servo center mode, the mandrel moves to either end of the stroke instead of to the center of its stroke. Remedy: Select “Manual” mode and change the servo center polarity of drive 2. Reference :CDP-01 Reference Manual, Section: “Servo Center Polarity”. Fault: In automatic mode, the mandrel does not accurately follow the sensor. Remedy: Perform the “Start/Sensor Positioner to mandrel ratio Calibration” procedure in this document

Fife CDP-01 controller

The advanced controller provides automatic Settings for fast and accurate operation

Can switch 115/220 VAC 50/60 Hz operation

Parallel interface for various functions :6 inputs (remote control), 2 outputs (alarm or indicator)

Automatically adjust the connected Fife motor

Built-in amplifier for transparent web page detection using infrared sensors

Automatic sensor control – Lost sensor signals (i.e., broken paper, reel end) will automatically switch to manual mode
