CE06250-2G308B1 增量编码器

Description

CE06250-2G308B1 增量编码器

特征：
增量编码器
扭矩更新高达 16 kHz
5V 至 24V 工作电压
两个双向 RS422 I/O
两个模拟输入
科尔摩根/丹纳赫 Motion SERVOSTAR CD SynqNet 驱动器是一款基于经过现场验证的 SERVOSTAR CD 驱动器系列的 SynqNet 伺服驱动器。功率级与CD相同，而控制级是专用的SynqNet设计。CD SynqNet 设计为扭矩驱动器，扭矩命令由 SynqNet 控制器以高伺服更新速率提供。提供广泛的 I/O 支持，包括特定功能输入（如限位开关、原位开关和制动器）以及众多通用 I/O。CD SynqNet 提供 N 分频功能，使其能够被编程为每 N 个驱动器编码器计数器寄存器产生一个输出脉冲。
SynqNet 是一款高性能全数字同步网络，专为多轴运动控制应用而设计。SynqNet 的物理层基于 IEEE 802.3 标准，用于以太网的物理层 100BASE-TX，而 SynqNet 的数据链路和应用层是专门为运动控制应用而设计的。100BASE-TX介质系统基于ANSI TP-PMD物理介质标准中公布的规范。100BASE-TX系统通过两对电线运行，一对用于“接收”数据信号，另一对用于“发送”数据信号。
CE06250：
• 反馈：编码器
• 额定电流：6 A
版本：3 相
配置：
• 输入电压：115/230 VAC
• 输入电流：10/7.8 安培/相
• 230 VAC 时的输入功率：1.8/2.8 KVA
• 输出电压：115/230 VAC
• 输出电流：6 安培/相
• 230 VAC 时的输出功率：1.4/2.2 KVA

CE06250-2G308B1

CE06250-2G308B1 增量编码器

Features:
Incremental encoder
Torque updates up to 16 kHz
Operating voltage from 5V to 24V
Two two-way RS422 I/O
Two analog inputs
Kors Morgen/Danaher Motion SERVOSTAR CD SynqNet Drive is a SynqNet servo drive based on the field-proven SERVOSTAR CD drive family. The power level is the same as the CD, while the control level is a dedicated SynqNet design. CD SynqNet is designed as a torque driver and torque commands are provided by the SynqNet controller at a high servo update rate. Extensive I/O support is available, including specific function inputs such as limit switches, in-situ switches, and brakes, as well as numerous general-purpose I/ OS. CD SynqNet provides an n-division function that enables it to be programmed to produce one output pulse per N driver encoder counter registers.
SynqNet is a high-performance, fully digital synchronous network designed for multi-axis motion control applications. SynqNet’s physical layer is based on the IEEE 802.3 standard for Ethernet’s physical layer 100BASE-TX, while SynqNet’s data link and application layer are specifically designed for motion control applications. The 100BASE-TX media system is based on the specifications published in the ANSI TP-PMD Physical Media Standard. The 100BASE-TX system operates through two pairs of wires, one for “receiving” data signals and the other for “sending” data signals.
CE06250:
• Feedback: encoder
• Rated current: 6 A
Version: 3 phases
Settings:
• Input voltage: 115/230 VAC
• Input current: 10/7.8 amps/phase
• Input power at 230 VAC: 1.8/2.8 KVA
• Output voltage: 115/230 VAC
• Output current: 6 amps/phase
• Output power at 230 VAC: 1.4/2.2 KVA
