DS200FCGDH1B是一种门分配和状态卡(FCGD)。该卡由通用电气为其Mark V板系列开发，可安装在许多通用电气品牌的驱动器中。安装后，该卡作为六脉冲，相位控制的不可逆桥的接口系统。DSPC(数字信号处理卡)将信息中继到该板进行破译。由此产生有关诊断信息和系统反馈的信号。这些反馈然后发送出去使用驱动器的集成VME背板。

DS200FCGDH1B从驱动器的集成dsc中收集大量数据。电路板接收到的信号被转换成小区门控信号。所有系统桥接支路接收这个单元门控信号，并将多路单元状态信息返回到该卡。FCGD板也接收反馈信号并进行缩放。三块FGPA板通过板上的光纤连接发送反馈信号。反馈包括频率、电压和单板状态信息。内置IMOK LED状态指示灯，为用户提供系统基本状态信息。

应满足制造商提供的电路板安装参数，以尽量减少设备故障或错误的风险。电路板的功能取决于正确地连接系统。DS200FCGDH1B的接线和安装指南可在设备的手册和数据表中找到。整个Mark V系列最初是由通用电气提供技术支持的。

axcontrol知识渊博的销售团队随时准备协助满足您的所有DS200FCGDH1B需求!接收当前的价格在这个部分，或任何其他部分或维修，请联系我们的工作人员通过电话或电子邮件。

DS200FCGDH1B

DS200FCGDH1B LCI 控制和门控保形涂层

The DS200FCGDH1B is a gate distribution and status card (FCGD). Developed by General Electric for their Mark V board series, this card can be installed in a number of GE brand drives. When installed, this card acts as an interface system for the six pulse, phase controlled non-reversing bridge. The DSPC (digital signal processing card) relays information to this board to decipher. From this, signals regarding diagnostic information and system feedbacks are produced. These feedbacks are then sent out using the drive’s integrated VME backplane.

DS200FCGDH1B collects a large amount of data from the drive’s integrated DSPC. Signals received by the board are translated into cell gating signals. All system bridge legs receive this cell gating signals and return multiplexed cell status information to this card. Feedback signals are also received and scaled by the FCGD board. Three FGPA boards send feedback signals via fiber optic connections found on board. Included feedback are frequency, voltage, and board status information. An integrated IMOK LED status indicator provides users with basic system status.

Manufacturer provided installation parameters for the board should be met to minimize risk of device malfunction or error. Board function is dependent upon wiring the system correctly. An illustrated guide to wiring and installing DS200FCGDH1B is available in the device’s manual and datasheet. The entire Mark V series was originally provided technical support by General Electric.

AX Control’s knowledgeable sales team is ready to assist with all of your DS200FCGDH1B needs! To receive current prices on this part, or any other part or repair, please contact our staff by phone or email.
