EasyGen-350-X 发电机组控制

Description

EasyGen-350-X 发电机组控制

EasyGen-350-X 发电机组控制

The easYgen-350/X provides automatic engine starting, stopping, metering and generator protection with AMF and transfer switching.

The easYgen-350/X offers automatic engine starting, stopping, metering, generator protection, AMF and transfer switching. The easYgen-300 series is designed for single unit isolated operation applications.

The multi purpose 6 digit 7 segment LED offers the ability to display measured values and alarm messages. The CAN bus operation adds the ability to display J1939 messages from an engine ECU.

Features:
Start/stop sequence for Diesel engines
Pre-glow control
Operating hours, service hours, and start counters
Configurable trip levels/delays/alarm classes
6 digit 7 segment LED for
Display of measuring values (V, f, speed)
Display of counters
Display of alarms
Display of ECU messages
PC and/or front panel configurable (selection of parameters for front panel configuration)
Password protected front panel configuration
15 entry event logger
Customized display using paper-strips

Benefits:
AMF/loss of mains auto start/stop
Complete engine and generator protection in one unit
True RMS sensing of voltage
Counters for operating hours, service hours, and starts
Freely configurable discrete inputs
Freely programmable relay outputs
PC and/or front panel configurable
Password protected front panel configuration
Event logger
Customized display using paper-strips
6.5 to 32.0 Vdc power supply
Front panel-mounting
Display of J1939 data
Visualization of J1939 DM1 / DM2 SPN-FMI er-ror messages
D+ charge alternator input/output
CE marked
Shock and vibration test approved
UL/cUL listed
