IS200EROCH1AED RX3i 系列的 1 GHz 中央处理器

Description

IS200EROCH1AED RX3i 系列的 1 GHz 中央处理器

GE Fanuc PACSystems RX3i 系列的 1 GHz 中央处理器。它有一个 Intel Celeron-M 微处理器，带有 20 MB 用户内存（也称为随机存取内存或 RAM）和 20 MB 闪存。作为可编程操控器，IS200EROCH1AED每秒可进行高达 32K 的 I/O 操作。它最多支撑 512 个程序块，每个块的最大大小为 128 KB。IS200ERGTH1AAA 运用双背板总线与 I/O 和智能选项模块通信。
像这样的 RX3i CPU 专为实时操控机器、流程和资料处理体系而规划。它们能够用 C 或 IEC（世界电工委员会）认可的五种编程言语中的三种进行编程。详细而言，从 IEC 言语列表中，您能够运用梯形逻辑（梯形图）、结构化文本或功用块图言语对 IC695CPU315 进行编程。只有次序功用图和指令列表言语选项不适用。
IS200EROCH1AED选用浮点算法，固件可在体系内晋级。自动定位的符号变量能够根据需要运用尽可能多的内存，最高可达 20 MB 的用户内存容量。CPU 出厂时装备有两个前置端口，一个 RS-485 串行端口和一个 RS-232 串行端口。因此，您同时拥有一个 9 针连接器和一个 15 针连接器。CPU 支撑 SNP、串行 I/O 和 Modbus 从站和主站串行协议。IS200EROCH1AED还支撑大多数较旧的 GE Fanuc 系列 90-30 模块和扩展机架。

IS200EROCH1AED RX3i 系列的 1 GHz 中央处理器

GE Fanuc PACSystems RX3i series of 1 GHz central processing unit. It has an Intel Celeron-M microprocessor with 20 MB of user memory (also known as random access memory or RAM) and 20 MB of flash memory. As a programmable controller, the IS200eroch 1AED can perform up to 32K of I/O operations per second. It supports up to 512 blocks, each with a maximum size of 128 KB. The IS200ERGTH1AAA uses a dual backplane bus to communicate with the I/O and Smart Options modules.
RX3i cpus like this are designed for real-time manipulation of machines, processes, and data processing systems.

They can be programmed in C or three of the five programming languages recognized by the IEC (World Electrotechnical Commission). In detail, from the IEC language list, you can program the IC695CPU315 using ladder logic (ladder diagram), structured text, or functional block diagram language. Only the order function diagram and instruction list language options are not applicable.

IS200EROCH1AED uses floating point algorithm, firmware can be promoted in the system. The automatically positioned symbol variables can use as much memory as needed, up to 20 MB of user memory capacity. The CPU comes with two front ports, an RS-485 serial port and an RS-232 serial port. So you have both a 9-pin connector and a 15-pin connector. The CPU supports SNP, serial I/O, and Modbus slave and master serial protocols. The IS200EROCH1AED also supports most of the older GE Fanuc series 90-30 modules and expansion racks.
