IS200VPROH2B-IS200VPROH1BEF-IS200VPWRH1AHD GE 专为燃气轮机控制系统设计的设备

Description

IS200VPROH2B-IS200VPROH1BEF-IS200VPWRH1AHD GE 专为燃气轮机控制系统设计的设备

通用电气（GE）制造的紧急跳闸端子板，如IS200VPROH2B-IS200VPROH1BEF-IS200VPWRH1AHD，是一款专为燃气轮机控制系统设计的设备。这款紧急跳闸端子板属于VIe系列，主要用于Mark VIe或Mark VleS控制系统中。它包含了两个用于总线和发电机电压输入的电压互感器（PTS），以及用于I/O包的条件速度信号输入。此外，它还具有十二个继电器，每个继电器顶部都有一根银色金属线。这些继电器分为白色和黑色，每排六个，共两排。

除了这些基本功能，IS200VPROH2B-IS200VPROH1BEF-IS200VPWRH1AHD还具有DC-37针连接器，可连接至端子板的电缆以作为备用跳闸继电器。在Mark VIe或Mark VleS控制系统中，后备保护由SPRO和PPRO/YPRO通过接线到继电器板形成。PTUR或YTUR、TTUR和主跳闸继电器端子板提供主保护。

安装时，这款紧急跳闸端子板被安装在DIN导轨上的金属板载体承载，也可以安装在用螺栓固定在面板上的金属板组件上。总的来说，IS200TREGH1BDC的主要用途是作为燃气轮机控制系统中用于跳闸紧急保护的端子板，提供后备保护以及主保护等功能，以确保燃气轮机的安全运行。

请注意，以上信息仅供参考，如需更详细的信息，建议直接联系通用电气（GE）或其相关部门。同时，在操作或安装此类设备时，务必遵循制造商的指导和安全规定，以确保人员和设备的安全。

IS200VPROH2B-IS200VPROH1BEF-IS200VPWRH1AHD GE 专为燃气轮机控制系统设计的设备

Emergency trip terminal boards made by General Electric (GE), such as IS200VPROH2B-IS200VPROH1BEF-IS200VPWRH1AHD, are designed for gas turbine control systems. This emergency trip terminal board belongs to the VIe series and is primarily used in Mark VIe or Mark VleS control systems. It includes two voltage transformers (PTS) for bus and generator voltage inputs, and conditional speed signal inputs for I/O packets. In addition, it has twelve relays, each with a silver metal wire at the top. These relays are divided into white and black, six in each row, a total of two rows.

In addition to these basic features, the IS200VPROH2B-IS200VPROH1BEF-IS200VPWRH1AHD also has a DC-37 pin connector that can be connected to a cable to the terminal board to serve as a backup trip relay. In Mark VIe or Mark VleS control systems, backup protection is formed by SPRO and PPRO/YPRO by wiring to the relay board. PTUR or YTUR, TTUR, and main trip relay terminal boards provide primary protection.

When installed, the emergency trip terminal board is carried on a metal plate carrier mounted on a DIN rail, or can be mounted on a metal plate assembly bolted to the panel. In general, the main use of the IS200TREGH1BDC is as a terminal board for trip emergency protection in the gas turbine control system, providing backup protection and main protection functions to ensure the safe operation of the gas turbine.

Please note that the above information is for informational purposes only and for more detailed information, it is recommended to contact General Electric (GE) or its relevant departments directly. At the same time, when operating or installing such equipment, it is important to follow the manufacturer’s guidance and safety regulations to ensure the safety of personnel and equipment.
