IS420YAICS1B GE 两个I/O以太网和模拟I/O端子板之间的接口

Description

IS420YAICS1B GE 两个I/O以太网和模拟I/O端子板之间的接口

IS420YAICS1B 是GE（通用电气）公司设计开发的模拟量I/O模块，它是GE Mark VIeS控制系统的一部分。Mark VIeS是一个先进的安全控制系统，主要应用于石化、化工等需要高度安全性的行业。

IS420YAICS1B模块被设计为最多两个I/O以太网和模拟I/O端子板之间的接口。它包含一个处理器板和一个特定于输入功能的采集板，兼容BPPC处理器板并支持V05.01或更高版本的固件。ControlST软件应为V06.01或更高版本。

该模块被配置为接受来自相关端子板的输入电压信号，并支持多达10个模拟输入。其中前8个可配置为5V或10V或4-20mA电流环路输入，后两个输入可设置为1mA或0-20mA电流输入。

在安装新的IS420YAICS1B模块之前，需要确保相关的端子板已牢固安装。然后，应将YAIC I/O包（或用于TMR配置的三个包）插入端子板连接器，并使用以太网端口附近的螺柱固定包。

IS420YAICS1B GE 两个I/O以太网和模拟I/O端子板之间的接口

IS420YAICS1B is an analog I/O module designed and developed by GE (General Electric), which is part of GE Mark VIeS control system. Mark VIeS is an advanced safety control system, mainly used in petrochemical, chemical and other industries requiring high security.

The IS420YAICS1B module is designed as an interface between up to two I/O Ethernet and analog I/O terminal boards. It contains a processor board and a capture board specific to input functions, is compatible with BPPC processor boards and supports firmware version V05.01 or later. The ControlST software should be V06.01 or later.

The module is configured to accept input voltage signals from the associated terminal boards and supports up to 10 analog inputs. The first eight can be configured with 5V or 10V or 4-20mA current loop inputs, and the last two can be configured with 1mA or 0-20mA current inputs.

Before installing a new IS420YAICS1B module, ensure that the terminal board is securely installed. The YAIC I/O packet (or three packets for the TMR configuration) should then be plugged into the terminal board connector and secured using studs near the Ethernet port.
