MVME172P-644L 具有 4 个 IP 插槽的 VME 嵌入式控制器

Description

MVME172P-644L 具有 4 个 IP 插槽的 VME 嵌入式控制器

MVME172P-644L 具有 4 个 IP 插槽的 VME 嵌入式控制器

Batteries are used.

Configuration:
• Processor: MC68LC060, 64 MHz with MMU
• Memory: 16 MB SDRAM
• Memory: 512 KB SRAM
• Memory: 2 MB Flash
• EIA-232D DCE Module, SIMM06

Part Number: 01-W3528F 08E

Features:
●60 MHz MC68060 or 64 MHz MC68LC060 processor
●16 MB configurable SDRAM
●512 KB SRAM with spare battery
●2 MB flash memory
●8K x 8 NVRAM and calendar clock with spare battery
●1 32-pin JEDEC socket for EPROM
The Emerson/MOTOROLA MVME172P4 series VME Embedded controllers with 4 IP slots allow VME embedded controller users to achieve the cost performance of the RISC architecture while maintaining the MC68000
Mark code compatibility. By combining the MC68060 superstandard performance with a wide range of optional features and IndustryPack interfaces, Oems can select the right product for their application, rather than paying for unwanted features.

The new “Petra “application-specific integrated circuit (ASIC) replaces functions previously implemented in IP2 chips, MC2 chips, and MCECC chips, improving the performance of the storage subsystem. The memory configuration switch enables customers to customize the memory size for applications that require a smaller memory configuration.
