MVME320B VMEbus智能温彻斯特/软盘控制器模块

Description

MVME320B VMEbus智能温彻斯特/软盘控制器模块

MVME320B VMEbus智能温彻斯特/软盘控制器模块

Part Number: 01-W3483B, 01-W3484B 02D, 01-W3484B 02C, 01-W3483B 02B

MVME320B VMEbus Intelligent Winchester / Floppy Disk Controller Module MOTOROLA
Manufacturers ：MOTOROLA
Model(s)  ：MVME320B
Additional Information ：VMEbus Intelligent Winchester / Floppy Disk Controller Module
Estimated Shipping Size
Dimensions: 263 × 58 × 28mm
Weight:.4.3 kg
Country of Origin: United States of America

Products Description
The Debugging Package for Motorola 68K CISC CPUs User’s Manual provides general information for the onboard firmware package for all Motorola 68000 CISC CPU and MPU VMEmodule boards. This document is bound in two parts. Part 1 (68KBUG1/D3) contains the Table of Contents and Chapters 1 through 3. Part 2 (68KBUG2/D3, this volume) contains Chapters 4 and 5, Appendices A through I, and the Index. This manual is intended for anyone who wants to design OEM systems, supply additional capability to an existing compatible system, or work in a lab environment for experimental purposes.

The following firmware packages and boards are covered in this manual: The firmware packages are referred to as 16XBug in this manual. The boards are referred to as MVME16X.

This manual describes the debugger, the debugger command set, the one-line assembler/disassembler, and system calls. These functional elements are common to all firmware packages. Installation, start-up, diagnostics tests, and environmental parameters are described in the diagnostic manuals for each of the firmware packages.

A basic knowledge of computers and digital logic is assumed. Motorola and the Motorola symbol are registered trademarks of Motorola, Inc. SYSTEM V/68 is a trademark of Motorola, Inc. Timekeeper and Zeropower are trademarks of SGS-THOMSON Microelectronics.

Features:
High Performance Data Channels
Front Panel Status LED
Three Front Panel Interface Connections
Single Slot VME Module
The Emerson / Motorola MVME320A VMEbus Intelligent Winchester/Floppy Disk Controller Module conforms to the single-slot VMEbus form factor. It provides high performance data channels between System memory and ST506 Winchester and/or floppy drives; up to two Winchester and two floppy disk drives or four floppy disk drives. The unit features a fail-inform LED and three interface connections on the front panel.
