PCI-6115 12位10ms /s/ch同时采样多功能数据采集卡

Description

PCI-6115    12位10ms /s/ch同时采样多功能数据采集卡

PCI-6115    12位10ms /s/ch同时采样多功能数据采集卡

Configuration:
• 32 MB Onboard Memory
• (4) Analog Inputs Boards Installed; Part Number: 187088D-01

Part Number: 184529D-01, 184529E-52

4-channel AI (12-bit, 10 MS/s/ch), 2-channel AO, 8-channel DIO, PCI Multi-function I/O device – PCI‑6115 is a synchronous sampling multi-function DAQ device. It provides analog I/O, digital I/O, two 24-bit counters, and digital triggers. PCI‑6115 is ideal for a variety of applications, such as excitation/response applications that require synchronous analog input (AI), analog output (AO), and digital I/O. It is also ideal for 42 V automotive applications, radar, sonar and ultrasound. The included NI‑DAQmx driver and configuration utility simplify configuration and measurement.
Based on the dimensions of PCI-6115, the required chassis slot must be able to accommodate the entire length of the PCI module.

Features:
4 High-Speed Analog Inputs, 10 MS/s per Channel
Software-Selectable Onboard Anti-Aliasing Filters
Two 12-Bit Analog Outputs, 4 MS/s Single Channel, 2.5 MS/s Dual Channel
8 Digital I/O Lines
Two 24-Bit Counters
Analog and Digital Triggering
The NI PCI-6115 features a dedicated analog-to-digital converter (ADC) per channel for maximum device throughput and higher multichannel accuracy. The deep onboard memory delivers reliable data streaming with fewer dependencies on bus availability. Half of the onboard memory is dedicated to analog input and the other half, to analog output. With 10 MS/s per channel sampling rates, eight input ranges from ±0.2 to ±42 V, to analog output. With 10 ms /s per channel sampling rates, eight input ranges from ±0.2 to ±42 V, onboard anti-aliasing filters, two 12-bit analog outputs, two 24-bit counter/timers and eight general-purpose digital I/O lines, the NI PCI-6115 can be used in a variety of applications.
