PCI-6561 LVDS 数字波形发生器/分析仪（16 Mb/通道）

Description

PCI-6561    LVDS 数字波形发生器/分析仪（16 Mb/通道）

PCI-6561   LVDS 数字波形发生器/分析仪（16 Mb/通道）

Settings:
• Memory :16mb /Channel
• Maximum clock frequency :100mhz

Part Number :191572A-01, 191572A-02, 188078E-01

Features:
Synchronization and storage core
Fast clock rate and low power consumption for LVDS signaling
16 channels with direction control per channel
NI PCI-6561 / PCI-6562 LVDS digital waveform generator/analyzer with synchronization and storage core, LVDS signal with fast clock rate and low power consumption, plus 16 channels, each channel direction control.

100 MHz, 16-channel digital waveform device – PCI‑6561 is a digital waveform generator and analyzer for connecting 16 low voltage differential signal (LVDS) digital pins. The device is capable of sampling digital waveforms at rates up to 100 MHz and can be connected to commonly used transistor-transistor logic (TTL) voltage levels. PCI‑6561 also has advanced synchronization capabilities.
