PXlE-5122 100 MHz、2 通道、PXI 示波器

Description

PXlE-5122 100 MHz、2 通道、PXI 示波器

美国国家仪器公司PXIe-5122高速数字化仪

美国国家仪器公司的PXIe-5122(部件编号:779967-01,779967-02和779967-03)高速数字化仪，基于SMC工程，伴随着快速存储器选择从8到512 MB的每个通道(4至2.56亿14位测试每通道)。NI PXIe-5122在无需软件干预的情况下，在多记录采集模式下采集超过100万个触发波形，用于雷达、超声波和事件识别等需要短触发重新启动时间的应用。此外，用户可以在单次拍摄和各种记录获取模式下以100 ps的分辨率为每个触发事件添加时间戳。PXIe-5122还可以从已安装的内存持久地传输信息，以便有更长的获取内存和流到磁盘。

每台美国国家仪器公司的数字化仪都配有符合NI- scope标准的NI- scope驱动程序，该驱动程序完全兼容NI LabVIEW、LabWindows/CVI和Measurement Studio for Visual Studio 6.0和。net。NI-SCOPE集成了50多个内置估计和检查能力，以及直观的SCOPE软前面板。

高分辨率NI PXI-5122示波器/数字化仪适用于汽车，通信，科学研究，军事/航空和消费电子领域的各种用途。

这个示波器配备了这些功能:

•100- mhz, 100 Msamples/sec, 14位数字化仪在PXI格式

•两个通道一直在14位分辨率下测试

•100 Msamples/sec实时和2.0 Gsamples/sec随机交错采样

•100mhz传输容量

•50欧姆或1欧姆输入阻抗，编程可选

•200mV到20V信息

•75 dBc SFDR和62 dB SINAD

•8、32或256兆字节的内存为每个通道

•边缘，窗口，滞后，视频和高级触发100 ps时间戳

•兼容的工作框架:Windows 2000/XP

•包括NI-SCOPE驱动程序编程

PXlE-5122

PXlE-5122 100 MHz、2 通道、PXI 示波器

National Instruments PXIe-5122 High-Speed Digitizer

The National Instruments PXIe-5122 (Part Numbers: 779967-01, 779967-02, and 779967-03) High-Speed Digitizer, based on the the SMC engineering, accompanies fast memory choices from 8 to 512 MB for each channel (4 to 256 million 14-bit tests per channel). The NI PXIe-5122 acquires more than 1 million triggered waveforms without software intervention in multiple-record acquisition mode for applications, such as RADAR, ultrasound, and event recognition, which require short trigger rearm times. Additionally, the user can timestamp each triggered event with 100 ps resolution in both single-shot and various record acquisition modes. The PXIe-5122 can also stream information persistently from installed memory to have memory for longer acquisitions and streaming to disk.

Each National Instruments Digitizer accompanies the IVI-compliant NI-SCOPE driver, which is completely compatible with NI LabVIEW, LabWindows/CVI, and Measurement Studio for Visual Studio 6.0 and.NET. NI-SCOPE incorporates more than 50 built-in estimation and examination capacities, along with an intuitive SCOPE Soft Front Panel.

The high-resolution NI PXI-5122 Oscilloscope/Digitizer is suited for a wide assortment of uses in automotive, communications, scientific research, military/aviation, and consumer electronics.

This Oscilloscope comes equipped with these features:

•           A 100-MHz, 100 Msamples/sec, 14-bit digitizer in PXI format

•           Two channels all the while tested at 14-bit resolution

•           100 Msamples/sec real-time and 2.0 Gsamples/sec random interleaved sampling

•           100 MHz transmission capacity

•           50 ohm or 1 Mohm input impedance, programming selectable

•           200mV to 20V info go

•           75 dBc SFDR and 62 dB SINAD

•           8, 32, or 256 Mbytes of memory for each channel

•           Edge, window, hysteresis, video, and advanced triggering with 100 ps timestamping

•           Compatible working frameworks: Windows 2000/XP

•           Includes NI-SCOPE driver programming
