Description

产品细节说明：RED521 1MRK002003-BA ABB 通用差动保护端子

1. 差动保护功能：
   • RED521 1MRK002003-BA通过比较进入和离开受保护区域的电流差异来检测故障，实现快速响应和故障隔离。这种差动保护机制对于防止电力系统中的短路、过载等故障具有重要意义。
2. 适应性强：
   • 该产品容易适应不同的变电站配置，具备广泛的自我监督功能，确保在各种工况下都能稳定工作。
3. 实时性与准确性：
   • 实时时钟与外部同步，确保时间戳的准确性。差动保护与操作时间通常只需10-15毫秒，提高了保护的实时性和准确性。
4. 低CT要求：
   • RED521 1MRK002003-BA对CT（电流互感器）的要求较低，只需2毫秒饱和即可正确操作，降低了对CT性能的要求。
5. 多种测量区与CT输入：
   • 一个三相端子带有一个测量区，为一个单一区域提供多达六个隔板的母线保护。三个单相端子带有两个测量区，为多达18个CT输入提供相分离的母线保护。
6. 监控与通信：
   • 提供事件列表功能，最多可记录16个事件，并显示每个阶段和保护区的模拟服务值。支持串行数据通信，便于与上层系统进行数据交换和监控。
7. 用户界面友好：
   • 内置本地人机界面与LED指示，方便用户进行状态查看和操作

RED521 1MRK002003-BA

产品详情参数 ：RED521 1MRK002003-BA ABB 通用差动保护端子

• 输入输出：支持1A或5A主电流互感器通过抽头连接的当前输入，具有一个或两个模拟输入模块，二进制输出模块有24个输出（在工厂预先配置），二进制输入模块有16个输入（在工厂预先配置）。
• 电源：电源模块覆盖24伏至250伏直流 ± 20%。
• 工作环境：工作环境温度为标准kHz
• 安装方式：现场安装，结构形式为模块式。

RED521 1MRK002003-BA ABB应用领域：

RED521 1MRK002003-BA是一款功能强大、适应性强的通用差动保护端子，广泛应用于电力系统的保护和控制领域。

Product Details: RED521 1MRK002003-BA ABB Universal Differential Protection Terminal
Differential protection function:
RED521 1MRK002003-BA detects faults by comparing the difference in current entering and leaving the protected area, achieving rapid response and fault isolation. This differential protection mechanism is of great significance in preventing faults such as short circuits and overloads in the power system.
Strong adaptability:
This product is easy to adapt to different substation configurations and has a wide range of self-monitoring functions to ensure stable operation under various working conditions.
Real time and accuracy:
Real time clock is synchronized with external devices to ensure the accuracy of timestamps. Differential protection and operation time usually only take 10-15 milliseconds, which improves the real-time and accuracy of the protection.
Low CT requirements:
RED521 1MRK002003-BA has lower requirements for CT (current transformer), and can operate correctly with only 2 milliseconds of saturation, reducing the requirements for CT performance.
Multiple measurement areas and CT inputs:
A three-phase terminal with a measurement area provides busbar protection for up to six partitions in a single area. Three single-phase terminals with two measurement zones provide phase separated bus protection for up to 18 CT inputs.
Monitoring and Communication:
Provide an event list function that can record up to 16 events and display simulated service values for each stage and protected area. Supports serial data communication, facilitating data exchange and monitoring with upper level systems.
User friendly interface:
Built in local human-machine interface and LED indicator, convenient for users to view and operate status
Product details and parameters: RED521 1MRK002003-BA ABB universal differential protection terminal
Input/output: Supports the current input of 1A or 5A main current transformers connected through taps, with one or two analog input modules, 24 outputs for binary output modules (pre configured at the factory), and 16 inputs for binary input modules (pre configured at the factory).
Power supply: The power module covers 24V to 250V DC ± 20%.
Working environment: The working environment temperature is standard kHz
Installation method: On site installation, modular structure.

RED521 1MRK002003-BA ABB application areas:

RED521 1MRK002003-BA is a powerful and adaptable universal differential protection terminal widely used in the protection and control fields of power systems.
