TM3TI4G 可以接受多种类型的输入

Description

TM3TI4G 可以接受多种类型的输入

TM3TI4G是一款模拟输入模块，通常用于Modicon M221、M241和M251逻辑控制器。它具有4个16位分辨率的模拟量输入通道，可以接受多种类型的输入，包括0到10V、-10到+10V、0到20mA、4…20mA的电流，以及多种热电偶类型（如K、J、R、S、B、E、T、N、C等），还有PT100、PT1000、NI100和NI1000等温度传感器信号。此外，TM3TI4G还具有卡簧端子块设计，方便连接。

该模块还具备环保特性，符合最新的环保法规，并倡导环境影响的透明度。它还支持施耐德电气的Green Premium承诺，旨在提供具备一流环保性能的产品，同时致力于减少产品对环境的影响。

在电气参数方面，TM3TI4G的额定电源电压为24Vdc，电源范围在20.4…28.8Vdc之间。其连接器具有至少100次的插入/拔出耐久性。在24Vdc的内部总线上，最大电流为0mA，而在外部24Vdc的情况下，最大电流为35mA。

关于TM3TI4G的外部尺寸，拔出卡扣后的尺寸为8.5毫米（0.33英寸）。

请注意，具体的安装步骤和参数设置可能会因模块型号和制造商的不同而有所差异。因此，在进行安装和配置之前，务必参考模块的用户手册或安装指南，并按照制造商的指示进行正确的操作。同时，也需要注意相关电气安全和操作规范，确保系统的稳定性和安全性。

TM3TI4G 可以接受多种类型的输入

TM3TI4G is an analog input module commonly used in Modicon M221, M241 and M251 logic controllers. It has four analog input channels with 16-bit resolution and can accept a variety of input types, including 0 to 10V, -10 to +10V, 0 to 20mA, 4… 20mA current, and a variety of thermocouple types (such as K, J, R, S, B, E, T, N, C, etc.), as well as PT100, PT1000, NI100 and NI1000 temperature sensor signals. In addition, TM3TI4G also has a circlip terminal block design for easy connection.

The module also has environmental features, complies with the latest environmental regulations and promotes transparency of environmental impact. It also supports Schneider Electric’s Green Premium commitment to provide products with best-in-class environmental performance while working to reduce their environmental impact.

In terms of electrical parameters, TM3TI4G has a rated power supply voltage of 24Vdc and a power supply range of 20.4… 28.8Vdc between. Its connectors have at least 100 insert/pull out durability. On the 24Vdc internal bus, the maximum current is 0mA, while on the external 24Vdc case, the maximum current is 35mA.

Regarding the external dimensions of the TM3TI4G, it measures 8.5 mm (0.33 in) when the buckle is pulled out.

Please note that the specific installation steps and parameter Settings may vary depending on the module model and manufacturer. Therefore, before installation and configuration, it is important to refer to the module’s user manual or installation guide and follow the manufacturer’s instructions to perform the correct operation. At the same time, it is also necessary to pay attention to the relevant electrical safety and operating specifications to ensure the stability and safety of the system.
