VE4003S2B1 标准I/O终止块

Description

VE4003S2B1 标准I/O终止块

VE4003S2B1 标准I/O终止块

Manufacturer : Emerson

Product Number : VE4003S2B1 8 Channels 4-20 mA, HART

Product type : Standard I/O Termination Block

Operating temperature : -40 to 70 °C (-40 to 158°F)

Storage temperature : -40 to 85 °C (-40 to 185 °F)

Relative humidity : 5 to 95% , non-condensing

Airborne contaminants : ISA-S71.04-1985 Airborne Contaminants Class G3 Conformal coating

Protection rating : IP 20

Shock : 10 g ½-sine wave for 11 ms

Dimensions (HxWxD), approx : 10.7cm x 4.1cm x 10.5cm

Shipping Weight : 1.5 Kg

Traditional I/O is a modular subsystem that offers flexibilityduring installation. It’s designed to be installed in the field,near your devices. Traditional I/O is equipped with functionand field wiring protection keys to ensure that the correct I/Ocard is always plugged into the corresponding terminal block.Modularity, protection keys, and plug-and-play capabilitiesmake DeltaV™ Traditional I/O a smart choice for your processcontrol system.
