VM600-IRC4 智能继电器卡

Description

VM600-IRC4 智能继电器卡

VM600-IRC4是VM600机架式机械监控系统的高质量、高可靠性智能继电器卡。它安装在VM600 ABE04x机架的后部，用于增强系统的控制功能。

该智能继电器卡具有额外的继电器，这些继电器由来自MPC4和/或AMC8卡的多达86个输入的方程驱动。这使得它在需要2oo3表决等更复杂的逻辑场景中得到应用。这些继电器可配置为8个SPDT或4个DPDT，并可通过IRC4配置器软件进行完全的软件配置。继电器可配置为正常通电（NE）或正常断电（NDE），并具有可配置的延迟。

此外，所有继电器触点均可在螺丝端子连接器上获得，这为用户提供了灵活性和方便性。总的来说，VM600-IRC4智能继电器卡通过其高质量、高可靠性的设计和功能，为VM600机架式机械监控系统提供了强大的支持。

VM600-IRC4 智能继电器卡

Vm600-irc4 is a high quality, high reliability intelligent relay card for VM600 rack mounted mechanical monitoring system. It is installed in the rear of the VM600 ABE04x rack and is used to enhance the control functions of the system.

The smart relay card features additional relays that are driven by equations with up to 86 inputs from MPC4 and/or AMC8 cards. This makes it useful in more complex logic scenarios that require 2oo3 voting, for example. These relays can be configured as 8 SPDTS or 4 DPDTS and can be fully software-configured via IRC4 Configurator software. Relays can be configured for normal power on (NE) or normal power off (NDE) and have configurable delays.

In addition, all relay contacts are available on the screw terminal connector, which provides flexibility and convenience to the user. Overall, the VM600-IRC4 intelligent relay card provides strong support for the VM600 rack-mounted mechanical monitoring system through its high-quality, highly reliable design and features.
