VMIVME-3801 32通道16位模数转换器模块

Description

VMIVME-3801 32通道16位模数转换器模块

安装选项
•40hz输入滤波器

部件编号:332-003801-100C

特点:
32路单端或16路差分输入
孤立Channel-To-Bus
自动扫描
输入范围:±50mv ~±10v或0 ~ 25mA
40khz聚合转换率
支持实时内置测试
低通输入滤波器:50 kHz，可选40 Hz
1500 V通道到总线隔离
与VMIC的通用I/O控制器兼容
VMIVME-3801 12位模数转换器(ADC)模块是一款中等性能的12位ADC模块，支持32个单端或16个差分前面板模拟输入。VMIVME-3801配备了自动扫描功能，可连续数字化输入并将结果存储在双端口数据寄存器中。VMIVME-3801 ADC板还具有内置测试功能，前面板Fail LED为用户提供故障检测和隔离功能。

VMIVME-3801

VMIVME-3801 32通道16位模数转换器模块

Installed Option
• 40 Hz Input filter

Part Number: 332-003801-100C

Features:
32 Single-Ended or 16 Differential Inputs
Isolated Channel-To-Bus
Autoscanning
Input Ranges from ±50 mV to ±10 V or 0 to 25mA
40 kHz Aggregate Conversion Rate
Supports Real-Time Built-in-Test
Low Pass Input Filters: 50 kHz, Optional 40 Hz
1,500 V Channel-To-Bus Isolation
Compatible with VMIC’s Universal I/O Controllers
The VMIVME-3801 12-bit Analog-to-Digital Converter (ADC) Module is a medium performance 12-bit ADC Module that is designed to support 32 single-ended or 16 differential front-panel analog inputs. The VMIVME-3801 is equipped with the Autoscanning feature to continuously digitize inputs and store the results in dual-ported data registers. The VMIVME-3801 ADC Board also features Built-in-Test functions, and a front panel Fail LED provides the user with the capability of fault detection and isolation.
